Sony VPL-PHZ10 Laser Light Source Projector
Overview
Cost-effective laser projection with excellent picture quality, easy installation and low running costs. The VPL-PHZ10 laser projector is a versatile, affordable choice for installation in a wide range of education, business and entertainment environments. The powerful Z-Phosphor laser light source is teamed with Sony’s advanced BrightEra 3LCD projection engine to deliver extremely bright, detail-packed WUXGA resolution images with generous 5000 lumens brightness and rich, stable colours.
This laser light source allows up to 20,000 hours* of virtually zero maintenance operation without the worry of sudden lamp failures. An automated filter system cuts the hassle of regular dust cleaning. Near-zero maintenance needs are complemented by a range of energy-saving features, significantly driving down total lifetime ownership costs. Constant Bright maintains consistent light output levels throughout the laser’s 20,000 hours (at light output mode “Middle”) recommended lifespan. Offering a stylish blend-in design and low fan noise, the VPLPHZ10 fits smoothly into almost any environment ‒ from academic institutions to corporate environments. Mount the projector at any angle, even on its side or upside down. Set-up’s
Features
Very high image quality with Sony’s advanced BrightEra 3LCD projection engine and Z-Phosphor laser light source. The Z-Phosphor laser light source is coupled with Sony’s acclaimed BrightEra 3LCD projection engine to ensure high 5000 lumen image brightness with vivid, natural colour reproduction.
Constant Brightness
Constant Bright maintains the same brightness of 4,500 lumens throughout the 14,000-hour recommended life span.* *When Constant Bright is on, and using ‘Standard’ light output mode
Advanced picture refinement technologies
Picture quality is boosted by advanced processing featured on Sony’s home cinema projectors. Reality Creation uses a powerful pattern-matching database to optimise every pixel. Contrast Enhancer actively analyses and refines dark and light image areas for sparkling highlights and rich, deep blacks.
Crisp, detail-packed WUXGA resolution images
See fine detail in PC presentations, videos or multimedia signage with WUXGA (1920 x 1200) 16:10 resolution.
Up to 20,000 hours* operation with virtually no maintenance
The advanced laser light source offers up to 20,000 hours* operation without lamp exchange, reducing lifetime running costs compared with traditional projectors. *Actual hours may vary depending on the Sage environment.
Hassle-free automatic filter cleaning
Focus on great-looking images instead of arduous maintenance tasks: new automated filter cleaning system removes dust every 100 hours. Energy-saving Reduce running costs even further with convenient energy-saving features: Picture Mute and Auto Dimming.
Save time with every presentation.
Quick power On/Off dramatically cuts warm-up time after switching on, before you can start presenting at full brightness.
360° free-angle installation capability
Enjoy greater installation flexibility: position the projector freely at any an,e ‒ or its side, or even upside down.
Supports HDBaseT
Simpler, more cost-effective installation and connectivity with digital transmission of HD video, audio and networking/control over a single Ethernet cable.
Quiet operation
Low fan noise ensures discreet, unobtrusive operation in quiet environments for academic and corporate use.
Slim, attractive blend-in design
The slim, stylish case design features a flat top surface that blends in discreetly when the projector is ceiling-mounted.
Picture Mode
Picture Mode ensures great-looking pictures in any presentation conditions. Select Standard, Dynamic, or Brightness Priority mode for optimised image quality, with any source and in every room. Easily adjust projector settings with the remote commander.
Specifications
| Lens shift – Range Vertical | +20% to +55% |
| Light source | |
| Type | Laser diode |
| Screen size | |
| Screen size | 40″ to 300″ (1.02 m to 7.62 m) |
| Light output *1 | |
| Mode: Standard | 5,000lm *2 |
| Mode: Standard (Centre) | 5,200lm *3 |
| Speaker | |
| Speaker | 16 W (monaural) |
| INPUT B | HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support |
| INPUT C | HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support |
| INPUT D | HDBaseT interface connector: RJ45, 4 play (Video, Audio, LAN, Control) |
| Heat dissipation | |
| AC 100 V to 120 V | 1446 BTU/h |
| AC 220 V to 240 V | 1374 BTU/h |
Disposal
For the Customers in Europe
The recycling of materials will help to conserve natural resources. For more detailed information about the recycling of this product, please contact your local Civic Office, your household waste disposal service, or the shop where you purchased the product.
Notice for the customers in the countries applying EU Directives > Manufacturer: Sony Corporation, 1-7-1 Konan Minato-ku, Tokyo, 108-0075 Japan. For EU product compliance: Sony Belgium, bijkantoor van Sony Europe Limited, Da Vincilaan 7-D1, 1935
For the Customers ithe n the Republic of India
Reduction in the Use of Hazardous Substances in Electrical & Electronic Equipment. This product and its components, consumables, parts, or spares comply with the hazardous substances restriction of India’s E-Waste (Management) Rules. The maximum allowable concentrations of the restricted substances are 0.1% by weight in homogenous materials for Lead, Mercury, Hexavalent Chromium, Polybrominated Biphenyls (PBB) and Polybrominated Diphenyl Ethers (PBDE), and 0.01% by weight in homogenous materials for Cadmium, except for the exemptions specified in Schedule II of the aforesaid Rules.
Customer Service
- Website: https://www.sony.com/
- Ph: 800-326-9551
FAQs
Q: What kind of projector is the VPL-PHZ10?
The BrightEra 3LCD engine and Sony’s “Z-Phosphor” laser light source are used in the VPL-PHZ10, a 3LCD installation-class projector that offers long-term dependability, great brightness, and stable colour.
Q: What’s the native resolution and aspect ratio?
WUXGA (1920 × 1200) with a 16:10 aspect ratio is the native resolution.
Q: How bright is the projector — will it work even in rooms with ambient light?
Yes, it can produce up to 5,000 ANSI lumens (colour and white), which makes it appropriate for meeting rooms, conference halls, classrooms, and well-lit spaces.
Q: What kind of light source does it use — lamp or laser?
Instead of using a conventional bulb, it uses a laser diode (Z-Phosphor laser light source), which has benefits in terms of longevity, reliability, and upkeep.
Q: How long will the light source last?
Compared to other lamp-based projectors, the projector has a rating of up to 20,000 hours of operation (in regular “Middle” mode).
Q: Is there maintenance required (e.g. filter cleaning)?
It requires less upkeep because it has an automated filter cleaning system that minimises dust accumulation and keeps the device operating dependably without the need for frequent manual filter cleaning.
Q: What screen sizes and throw distances does it support?
Depending on throw distance and magnification, the VPL-PHZ10 can accommodate a wide range, from roughly 40 inches to 300 inches diagonal (≈ 1.02 m to 7.62 m), making it suitable for both small and large spaces.
Q: What is its throw ratio/zoom/lens shift flexibility?
The range of the throw ratio is from 1.28:1 to 1.88:1. It features manual focus, manual zoom (1.45×), and lens-shift (horizontal ±10%, vertical shift from +20% to +55%).
